home > products show > woven wire fence > PVC Coated chain link fence

PVC Coated chain link fence, diamond wire mesh, Diamond link fence

We can supply PVC coated chain link fence for export in Green, blue, beige and custom colors. The powder coated steel fence netting is supplied with posts, caps, top rails, tubular line posts and gates with the same treatment. PVC coated Chain Link Fence is a kind of flexible woven wire mesh fence. It can be designed with chain link swing or slide gates, barbed wires, razor wire and other accessories to make a system fencing for specific uses.

Property of chain link fence with coating layer: Corrosion resistance, aging resistance, sunshine resistance and weather resistance.

PVC coated Galvanized Chain link fence for events barriers and mobile fencing uses.

PVC coated chain link fence ( in Roll), portable:

3mm( After PVC Coating 1.8mm wire)×5×5cm×1×15m
3mm(After PVC Coating 1.8mm wire )×5×5cm×1.8×15m
3mm( After PVC Coating,2mm wire )×5×5cm×1×15m
3mm(After PVC,2mm wire )×5×5cm×1.8×15m
2.7mm( Before PVC)×5×5cm×1×15m
2.7mm( Before PVC)×5×5cm×1.8×15m
Electro. galvanized chain link fence ( in Roll) with pvc coating:

Wire rolls

3mm( After PVC)
2,7mm( Before PVC)
2.7mm Galvanized
3mm Galvanized

Chain Link Fencing is extensively used as fences for playground and gardens, super highway, railway, airport, port, residence, etc. Also can be used for breeding of animals. Detail specifications as listed below.

We Offers:
PVC Coated Chain Link Fencing (Green, Black, etc.)
Electro Chain Link Fencing With 7-15G per Square Meter Zinc Coating;

Wire diameter
18# - 13#
16# - 8
1.2 - 2.4mm
1.6mm - 4.2mm
Length of the roll
0.50m - 100m(or more)
Width of the roll
0.5m - 5.0m
Materials and specifications can be made according to customers'detailed requirements.

Export list is as follows:

Number 1:

We produce PVC Chain link fence and Euro Fence,Exports to Netherlands.

Specifications and features:

PVC chain link fence ( Opening 2”x2”) ( Wire Diameter 2.76mm) (Length of the roll =400mtr) (Width of the roll = 5mtrs).

Euro Fence the same specification

1)Chain Link, galvanised 2 . 4 metre  height, 1,000 Meters
2)Barbed wire, total length of perimeter x 12, 11,000 Meter
3)Chain Link 4 meter height,300 Meters
4)Barbed wire, total length of perimeter x 12, 3000 Meters

Number 2:

We produce PVC Chain link fence for yard, Exports to Australia.

PVC coated Chain Link Fence for yard. It will be buried 2 feet into the ground, and will be 6 feet above ground (Picture attached dots are 14 feet centers:

Color: all components Galvanized and Hunter Green color Vinyl coated,
Fabric: 500 running feet, 8’ high, 9 gauge, 1” mesh,

6 = Corner Posts 2-3/8” Dia x 8 foot,.16 gauge
6 = 2-3/8in Post corner mounts

3 = End Posts 2-3/8” dia x 8 foot, 16 gauge
3 = End Post mounting sets 2-3/8in
3 = 2-3/8in Post Cap

60 = Line posts 1-5/8” dia, x 8 foot tall, 16 gauge,
60 = Loop caps to hold top rails

72 = Top Rails (500 divided by 7 = 72)

Top Rail end caps

2 = Gates (Drive Gates) 10 feet wide (5 foot per panel), 6 feet tall,
4 = gate hard ware sets, includes 4 Gate Hinge points.

36 = 2-3/8in Tension Band

there is also other miscellaneous parts needed to hold the fabric to the posts, and the top rails. the other components needed all Hunter Green color Vinyl coated.

Number 3:

We produce PVC Chain link fence for project in U.A.E.

We produce chain link fence for project in U.A.E.

Please find below the details for chain link below:

Technical data:
- Galvanized iron wire with Plastic-Coated (PVC);
- Color: Green.
- Mesh: 50x50mm;
- Wire diameter: 2,5-2,8mm
- Width of the roll: 2000mm
- Length of the roll: 20mt

Total quantity of fence : 50,000 m

Chain Link opening size: 2 inch x 2 inch x 3.2 mm thickness and 1.8 m height (PVC Coated)

Post height = 2.8 m

Post quantity = 7500 nos

12 x 15m rolls ( or 6 x 30m rolls ) with a 2.5" opening, 2.5mm wire diameter and 1.2m high.

Accessories: include all related accessories and quantities.
